UC-50
- Automatic start, stop and clear.
- UV, MG, MT, IR, DD detection while counting.
- Automatic half-note, chain-note, double note-detection.
- Batch, add and self-examination function.
- LCD color change to red when detect fake note.
- With total value calculating function (optional).
- Software can be updated through RS-232 port.
- Suitable for Pakistan and most currencies of the world.
Automatic Cash Counting Machine - UC-50
The UC‑50 Automatic Cash Counting Machine, available through KBSE, provides efficient and secure note counting with fully automatic start, stop, and clear functions. It includes comprehensive counterfeit detection using UV (Ultraviolet), MG (Magnetic), MT (Magnetic Thread), IR (Infrared), and Dimensional Detection, ensuring high reliability in cash handling operations. The system also detects double notes, half notes, and chain notes, enhancing counting accuracy and error prevention. Designed for intuitive usability, the UC‑50 features an LCD display that turns red when a suspect note is detected, with memory‑mode to maintain the last operating state. KBSE equips the UC‑50 with trusted support and service coverage, making it an ideal choice for banks, retail outlets, and finance centers that require dependable, fast, and secure cash processing capabilities.
Specifications
- Hopper Capacity: 500 bills
- Stacker Capacity: 200 bills
- Counting Speed: >1000 pcs/min
- Dimension: 290x255x165 mm
- Power Supply: AC220V±10% 50Hz or AC110V±10% 60Hz
- Size of Countable Notes: 50x110-90x180 mm
- Thickness of Countable Notes: 0.075-0.15mm
- Net Weight: 5.0 kg
- Gross Weight: 5.5 kg
- Power Consumption: 80W
- Counting Display: 4 digits
- Batch Display: 3 digits
