UC-200
- Automatic start, stop and clear.
- With UV, MG, IR, 3D (optional), Color (optional) detections.
- Automatic half-note, chain-note, double note-detection.
- With batch, add and self-examination function.
- Software can be updated through RS-232 port and USB port (optional).
- Mix value counting and denomination sort function.
- Suitable for Pakistan and most currencies of the world.
Mix Note Counting Machine - UC-200
The UC‑200 from KBSE is a sophisticated automatic note counting machine that supports UV, MG, IR, 3D, and colour detection while counting ensuring advanced counterfeit protection in every batch. It features auto start, stop, clear, along with detection of double notes, half notes, and chained notes for enhanced accuracy on every count. Additional capabilities include batch and add functions, and self-examination mode to support efficient cash management operations. The machine’s software can be updated via RS‑232 and USB ports, enabling compatibility with new currencies or evolving detection requirements. With hopper capacity for ~500 new or 300 used bills and stacker capacity for ~200 bills, the UC‑200 handles routine high-volume cash-counting needs efficiently. Designed for financial institutions, retail cash desks, and corporate cash centers, this model ensures secure, fast, and precise note processing supported by KBSE’s full technical and after-sales coverage.
Specifications
- Hopper Capacity: 200 bills
- Stacker Capacity: 200 bills
- Counting Speed: >1000 pcs/min
- Dimension: 300x235x200 mm
- Power Supply: 220V±10% 50Hz or AC110V±10% 60Hz
- Size of Countable Notes: 50x110-90x190cm
- Thickness of Countable Notes: 0.075-0.15mm
- Net Weight: 6 kg
- Gross Weight: 6.5 kg
- Power Consumption: 80W
- Counting Display: 4 digits
- Batch Display: 3 digits
