Survey

& GPS & Supplies & Accessories

Measuring Wheel

Survey Supplies

A surveyor's wheel, also called a click wheel, hodometer, waywiser, trundle wheel, measuring wheel, or perambulator is a device for measuring distance.

Digital Measuring Wheel

Large display located near handle for easy viewing
Stores up to 8 different measurements in memory
Measures up to 999,999metres/km/feet/miles
Bright yellow 'safety' color with reflectors
Takes true 'wall-to-wall 'measurements
Shower proof, rugged casing

Data Sheet

Measuring Wheel

Rubber wheehaluminum foldable handle.
Precision counter with wheel braker.
Circumference of wheel:1m
Measuring range:9999.9m,CM can be read out from the wheel.
Comes with carry bag
Weight:2.5kg.

Data Sheet

Distance Meters & Range Finders

Survey Supplies - A rangefinder is a device that measures distance from the observer to a target, for the purposes of surveying, navigation and determining focus. Some devices use active methods to measure (such as sonar, laser, or radar)

Laser Range Finder

Ranging method: semiconductor laser (harmless to eyes)
Ranging distance: 15-600m(LRF600X)
Focusing mode: eyepiece focusing
Ranging display mode: LCD display
Effective objective diameter: 24mm
Ranging error: ±1m±0.1%

Data Sheet

Distance Meter

Single Person Operation
Laser clearly indicates the target
Physical bubble vial ensures the measure is horizontal
Ergonomic design

Data Sheet

Tripod Stands

Survey Supplies - A tripod is a portable three-legged frame, used as a platform for supporting the weight and maintaining the stability of some other object. A tripod provides stability against downward forces and horizontal forces and movements about horizontal axes.

SJW30 Wooden Tripod

Heavy duty hardwood legs and aluminum die casting parts.
Wing nut clamp system.
Legs has one hole for easy hand carry.
Closed length: 109cm; opened length: 175.5cm
Weight: 7.5KG.

Data Sheet

SJW20 Wooden Tripod

Hardwood legs and aluminum die casting parts.
Wing nut screw or quick release clamp for option.
Closed length:1 03cm,opened length:171cm
Diameter of tripod head:160mm
Weight:4.5KG

Data Sheet

SJA50 Aluminum Tripod

Heavy duty construction.
Three hexagonal screws on the tripod head to adjust the legs tension.
Closed length:1 01 cm,opened length:171cm.
Diameter of tripod head:160mm
Wing nut screw or quick release clamp for option.
Weight:4.5 kg.

Data Sheet

Pole Stand

Closed length: 78cm opened length:115cm
Ball type head and telescopic legs.
Strong Grip & Convenient handling
Shower proof, Rugged casing
Heavy duty metallic finish
Weight:1.5kg

Data Sheet

Prism & Poles

Survey Supplies - In optics, a prism is a transparent optical element with flat, polished surfaces that refract light. At least two of the flat surfaces must have an angle between them. The exact angles between the surfaces depend on the application.

Prism Poles

Compression locking system made by metal parts.
Extension up to 4.6m.
5/8" adapter and Leica adapter
'With carry bag.
Weight:1.8kg..

Data Sheet

Ranging Poles

20cm Red/White banded color plastic coated painting.
Telescopic precision steel tube with twist lock.
Available in 2m.3m.With Carry bag
Shower proof, Rugged casing
Heavy duty metallic finish

Data Sheet

Prism Set

Type :Single Prism Package
Prism Offset:0 mm/-30mm
Prism Holder Color : Yellow
Soft Pouch Model: General Model

Data Sheet

Tribrach & Adapters

Survey Supplies - Tribrach (instrument), a device used in surveying for mounting an instrument on a surveyor's tripod. An adapter is a device that converts attributes of one device or system to those of an otherwise incompatible device or system
